OXPLO CPD35 Electric Forklift

3,500kg Lithium Electric Forklift for Heavy-Duty Material Handling

The OXPLO CPD35 is a 3.5 ton electric forklift designed for heavier pallet transport, stacking, loading and industrial material-handling applications.

With a rated lifting capacity of 3,500kg at a 500mm load center, a 76.8V / 280Ah lithium-ion battery system and a reinforced industrial chassis, the CPD35 combines higher lifting capacity with the clean and quiet operation of an electric forklift.

It is suitable for warehouses, logistics centers, manufacturing facilities and paved industrial yards where reliable lifting performance, controlled maneuverability and reduced exhaust emissions are important.

Technical Specifications

可以，全部左对齐更统一，英文参数表这样看也更自然。

Category	Parameter	CPD35 Specification
Capacity	Rated lifting capacity	3,500kg
	Load center distance	500mm
Dimensions	Overall length with fork	3,975mm
	Overall length without fork	2,755mm
	Overall width	1,225mm
	Overhead guard height	2,150mm
	Wheelbase	1,760mm
	Minimum ground clearance at mast	130mm
Mast & Fork	Free lifting height	145mm
	Mast tilt angle, front / rear	6° / 12°
	Fork size (L × W × T)	1,220 × 125 × 50mm
Performance	Maximum travel speed, full / no load	18 / 19.5km/h
	Maximum lifting speed, full / no load	380 / 450mm/s
	Maximum gradeability, full / no load	15% / 18%
Maneuverability	Minimum outer turning radius	2,515mm
	Minimum right-angle stacking aisle width	2,545mm
Tires & Weight	Front / rear tire size	28×9-15 / 6.50-10
	Total forklift weight	4,610kg
Battery	Battery voltage / capacity	76.8V / 280Ah lithium-ion

Core Performance Features

76.8V / 280Ah Lithium Battery System

The OXPLO CPD35 is equipped with a 76.8V / 280Ah lithium-ion battery system, providing stable electrical power for lifting, travel and daily industrial material-handling operations.

The intelligent Battery Management System monitors key battery conditions, including voltage, temperature and state of charge. It helps protect the battery against overcharging, over-discharging and overheating during operation.

Charging arrangements can be selected according to the customer’s working schedule and operating requirements.

Actual operating and charging times vary depending on:

• Load weight
• Lifting frequency
• Travel distance
• Gradients
• Working temperature
• Operator behaviour
• Charger configuration

For longer daily operating hours or multi-shift applications, the battery and charging arrangement should be matched to the customer’s actual duty cycle.

Clean and Quiet Electric Operation

The CPD35 electric powertrain produces no tailpipe emissions during operation and operates at a lower noise level than a comparable diesel forklift.

This makes the CPD35 suitable for applications such as:

• Indoor warehouses
• Logistics and distribution centers
• Manufacturing facilities
• Building-material warehouses
• Production and assembly areas
• Loading and unloading operations
• Industrial material handling
• Other environments where reduced exhaust emissions and lower operating noise are preferred

For cold-storage or low-temperature applications, suitable battery, hydraulic oil and electrical configurations should be confirmed according to the actual operating temperature.

3,500kg Heavy-Duty Lifting Capacity

The OXPLO CPD35 has a rated lifting capacity of 3,500kg at a 500mm load center, making it suitable for handling heavier pallets and industrial materials beyond the typical 2–3 ton warehouse forklift range.

Typical applications include:

• Heavy pallet transport
• Rack stacking
• Production-line material supply
• Truck loading and unloading
• Building-material handling
• Machinery and component handling
• General industrial logistics

Maximum lifting speed is:

• 380mm/s with a full load
• 450mm/s without a load

The rated 3,500kg capacity applies under the specified load-center and mast conditions.

If the load center exceeds 500mm, a higher mast is installed or a heavy attachment is fitted, the available residual lifting capacity may be reduced.

Maneuverability for Industrial Operations

Higher lifting capacity does not necessarily require excessive operating space.

The CPD35 combines its 3.5 ton capacity with practical dimensions and responsive steering to support warehouse and industrial material-handling operations.

Key maneuverability specifications include:

• Minimum outer turning radius: 2,515mm
• Minimum right-angle stacking aisle width: 2,545mm
• Overall width: 1,225mm
• Wheelbase: 1,760mm

These dimensions allow the CPD35 to maneuver efficiently in suitable warehouse aisles, loading areas and production facilities.

Actual aisle requirements depend on pallet dimensions, fork length, mast configuration, attachments and required safety clearance.

Customers should confirm their warehouse layout before selecting the final forklift configuration.

Stable Travel and Ramp Performance

The CPD35 provides maximum travel speeds of:

• 18km/h with a full load
• 19.5km/h without a load

Under specified test conditions, maximum gradeability is:

• 15% with a full load
• 18% without a load

This allows the forklift to handle suitable warehouse access ramps and paved industrial yards.

The CPD35 is primarily intended for level or paved operating surfaces.

Muddy ground, deep gravel, severe potholes and highly uneven agricultural or construction sites generally require a dedicated rough-terrain forklift.

Operator Comfort and Controlled Handling

The CPD35 operator area is designed to support comfortable and controlled operation during repeated material-handling cycles.

Clearly arranged controls, good mast visibility and responsive steering help the operator position heavier pallets accurately.

A digital instrument display provides essential operating information and allows the operator to monitor forklift and battery conditions during operation.

Depending on the selected configuration, available safety and operator-assistance equipment may include:

• Warning lights
• Reversing alarms
• Cameras
• Additional work lights
• Operator-protection equipment
• Other safety accessories

Available equipment should be confirmed according to the selected configuration and working environment.

Simplified Electric Forklift Maintenance

Compared with an internal-combustion forklift, the CPD35 lithium electric forklift eliminates a number of routine engine-related maintenance requirements.

There is no diesel engine requiring routine service items such as:

• Engine oil changes
• Fuel-filter replacement
• Engine belt servicing
• Other combustion-engine maintenance

The accessible electrical system allows technicians to inspect the lithium battery, controller and electrical connections more conveniently.

The Battery Management System also assists with battery-condition monitoring and identification of abnormal operating conditions.

However, electric does not mean maintenance-free.

Regular inspection is still required for:

• Lithium battery and charging system
• Tires and wheel components
• Brakes and steering system
• Hydraulic oil and hoses
• Mast rollers
• Lifting chains
• Forks and attachments
• Electrical connections

The simplified electric powertrain can reduce routine engine-related maintenance compared with an internal-combustion forklift while supporting reliable daily operation.

Durable Industrial Construction

The OXPLO CPD35 uses a reinforced mast, stable chassis structure and heavy-duty pneumatic tires for frequent industrial material handling.

Key structural specifications include:

• Total forklift weight: 4,610kg
• Front tire size: 28×9-15
• Rear tire size: 6.50-10
• Fork dimensions: 1,220 × 125 × 50mm
• Mast tilt angle: 6° forward / 12° backward
• Minimum ground clearance at mast: 130mm

The chassis and lifting system are designed to support repeated transport, stacking and loading of heavier pallets and industrial materials.

For operations involving loose soil, deep gravel, mud or highly uneven ground, a dedicated rough-terrain forklift should be considered instead.

Mast Configurations and Forklift Attachments

The CPD35 can be configured according to the customer’s load type, required lifting height and material-handling application.

Available configurations may include:

• Different mast heights
• Two-stage or three-stage mast
• Side shifter
• Fork positioner
• Extended forks
• Additional hydraulic functions
• Warning and safety equipment
• Alternative tire configurations

When handling loads approaching 3,500kg, forklift selection should consider more than maximum load weight.

Important factors include:

• Actual load weight
• Load dimensions
• Load center
• Required lifting height
• Mast configuration
• Attachment type
• Attachment weight
• Required residual lifting capacity

Attachments and extended load centers can reduce available lifting capacity, particularly at greater lifting heights.

OXPLO recommends confirming the complete working conditions before selecting the final CPD35 configuration.

OXPLO Forklift Selection and Technical Support

OXPLO supports international customers with forklift selection, configuration guidance, technical documentation and spare-parts support.

To determine whether the CPD35 is suitable for an application, customers can provide:

• Maximum load weight
• Required lifting height
• Pallet or load dimensions
• Actual load center
• Minimum aisle width
• Indoor or outdoor application
• Daily operating hours
• Working surface
• Required attachments
• Destination country or delivery location

Based on these working conditions, OXPLO can help recommend a suitable forklift, battery, mast and attachment configuration.

Frequently Asked Questions

Q1: What is the rated lifting capacity of the OXPLO CPD35?

The CPD35 has a rated lifting capacity of 3,500kg at a 500mm load center.

Actual available capacity may change when higher masts, attachments or loads with extended load centers are used.

For heavy or unusually shaped loads, customers should provide the complete load dimensions and required lifting height before finalizing the forklift configuration.

Q2: How long can the CPD35 operate on one charge?

The CPD35 uses a 76.8V / 280Ah lithium-ion battery system.

Actual operating time depends on load weight, lifting frequency, travel distance, gradients, operating temperature, operator behaviour and charger configuration.

OXPLO can help evaluate expected operating time according to the customer’s actual duty cycle.

Q3: Can the CPD35 support extended daily operating hours?

The CPD35 can support longer operating schedules when its battery and charging arrangement are correctly matched to the required duty cycle.

For multi-shift or extended-hour applications, customers should provide their working schedule so that the charging arrangement can be evaluated accordingly.

Q4: Can the CPD35 electric forklift be used outdoors?

Yes. The CPD35 can be used on suitable level and paved outdoor surfaces when weather and operating conditions permit.

It is not a dedicated off-road forklift.

For mud, deep gravel, severe potholes or highly uneven construction and agricultural surfaces, a rough-terrain forklift is generally more suitable.

Q5: Is a 3.5 ton electric forklift suitable for my load?

A 3.5 ton electric forklift should not be selected based only on maximum load weight.

Customers should also consider:

• Load dimensions
• Load center
• Required lifting height
• Attachment weight
• Mast configuration
• Residual lifting capacity

The CPD35’s 3,500kg rating applies at the specified 500mm load center under the relevant rated conditions.

Loads with an extended center of gravity, greater lifting heights or heavy attachments can reduce the forklift’s available lifting capacity.

Q6: How much aisle space does the CPD35 require?

The CPD35 has a minimum outer turning radius of 2,515mm and a minimum right-angle stacking aisle width of 2,545mm.

Actual operating-space requirements also depend on pallet dimensions, fork length, mast configuration, attachments and required safety clearance.

OXPLO recommends confirming the warehouse layout before selecting the machine.

Q7: Does the CPD35 require regular maintenance?

Yes.

Although its electric powertrain eliminates many diesel-engine maintenance items, regular inspection is still required for the lithium battery, charger, brakes, steering system, tires, hydraulic system, mast, lifting chains, forks and electrical connections.

Q8: What information should I provide before ordering a CPD35?

For a more accurate recommendation, provide:

• Maximum load weight
• Load dimensions
• Load center
• Required lifting height
• Minimum aisle width
• Daily operating hours
• Working surface
• Required attachments
• Delivery destination

OXPLO can then help determine an appropriate CPD35 battery, mast and attachment configuration for the application.

Request a CPD35 Forklift Recommendation

Looking for a 3.5 ton lithium electric forklift for warehouse, manufacturing, logistics or industrial material handling?

Send OXPLO your maximum load weight, load dimensions, lifting height, aisle width, daily operating hours and required attachments.

OXPLO will help determine whether the CPD35 electric forklift is suitable for your application and recommend the corresponding battery, mast and attachment configuration.
